OpenFOAM Basic Training

In this OpenFOAM® tutorial series, fourteen case examples have been prepared that are designed to help users to learn the key utilities and features within OpenFOAM®, including mesh generation, multiphase modeling, turbulence modeling, parallel processing and reaction modeling. The base tutorial examples can be imported directly from the OpenFOAM® installation directory. The tutorials should be primarily used for OpenFOAM® v10 but with slight differences, generally applicable to the other flavors of OpenFOAM® such as ESI-version and foam-extend! The structure of each case example follow the below general structure:

0. Background: an introduction about the key topics explored in the tutorial and the relevant CFD theory

1. Pre-processing: instructions on how to set up the correct case structure for a given problem using base case tutorials, with explanations on relevant dictionaries

2. Running simulation: instructions on running the solver and its associated commands

3. Post-processing: examining the results in OpenFOAM ® ’s post-processing application, ParaView V5.10.1

Introduction

keyboard_arrow_down

Editorial board:

  • Bahram Haddadi
  • Christian Jordan
  • Michael Harasek

Compatibility:

  • OpenFOAM® v10

Tutorials

keyboard_arrow_down

Full Tutorials

Tutorial One: Basic Case Setup

Solver: icoFoam

Geometry: 2-dimensional

Tutorial: elbow

1

Tutorial Two: Built in Mesh

Solver: rhoPimpleFoam

Geometry: 2-dimensional

Tutorial: forwardStep

2

Tutorial Three: Patching Fields

Solver: rhoPimpleFoam

Geometry: 1-dimensional

Tutorial: shockTube

3

Tutorial Four: Discretization – Part 1

Solver: scalarTransportFoam

Geometry: 1-dimensional

Tutorial: shockTube

4

Tutorial Five: Discretization – Part 2

Solver: scalarTransportFoam

Geometry: 2-dimensional

Tutorial: circle

5

Tutorial Six: Turbulence, Steady state

Solver: simpleFoam

Geometry: 2-dimensional

Tutorial: pitzDaily

6

Tutorial Seven: Turbulence, Transient

Solver: pisoFoam

Geometry: 2-dimensional

Tutorial: pitzDaily

7

Tutorial Eight: Multiphase - VoF

Solver: interFoam

Geometry: 2-dimensional

Tutorial: damBreak

8

Tutorial Nine: Parallel Processing

Solver: compressibleInterFoam

Geometry: 3-dimensional

Tutorial: depthChare3D

9

Tutorial Ten: Residence Time Distribution

Solver: simpleFoam, scalarTransportFoam

Geometry: 3-dimensional

Tutorial: TJunction

10

Tutorial Eleven: Reaction

Solver: reactingFoam

Geometry: 3-dimensional

Tutorial: reactingElbow

11

Tutorial Twelve: snappyHexMesh – Single Region

Solver: snappyHexMesh, scalarTransportFoam

Geometry: 3-dimensional

Tutorial: flange

12

Tutorial Thirteen: snappyHexMesh – Multi Region

Solver: snappyHexMesh, chtMultiRegionFoam

Geometry: 3-dimensional

Tutorial: snappyMultiRegionHeater

13

Tutorial Fourteen: Sampling

Solver: rhoPimpleFoam

Geometry: 3-dimensional

Tutorial: shockTube

14

Slide-set

keyboard_arrow_down

Author:

  • Bahram Haddadi

SlideSet

Appendix

keyboard_arrow_down

Appendix A: Important Commands in Linux

Compatibility: Unix (Linux, Alpha Unix …)

A1

Appendix B: Running OpenFOAM®

Compatibility: OpenFOAM v10

A2

Appendix C: Frequently Asked Questions

Compatibility: Unix (Linux, Alpha Unix …), OpenFOAM v10

A3

Appendix D: Paraview

Compatibility: ParaView 5.10.1

A4

Archive

keyboard_arrow_down

OpenFOAM Basic Training

Compatibility:

  • OpenFOAM® 2.3.0

OF2

OpenFOAM Basic Training

Compatibility:

  • OpenFOAM® 5
  • OpenFOAM® v1712

OF5

OpenFOAM Basic Training

Compatibility:

  • OpenFOAM® 7
  • OpenFOAM® v1906

OF7
